LOQED Touch Smart Lock black Installation guide

Door thicknesses: up to 110mm for a symmetric door, or up to 55mm measured from the cylinder screw.

The most common center-to-center distances: PC 55, 72, 92 and 110 mm.

Any backset larger than or equal to 30 mm.

Anti plug pulling door hardware covering the cylinder.

Multi-point door locks – whether they have three, five or seven bolts.

Handle operated doors, where the handle needs to be lifted to lock the door. You still have to manually lift the handle upward after closing the door.

Door locks where the lock cylinder is above the handle.

Sliding doors that have a extra long handle on the inside.

Doors where both sides are exposed to the weather or very low temperatures. This is generally the case for gates and unheated sheds. Only the outside module is fully waterproof.

Doors with rim locks, as these have a different cylinder profile. We recommend changing these locks for a SKG certified multi-point Euro profile lock.

Locks where you need to turn the key, lift the handle, and turn the key again. These locks are very rare.

Outside module: 51mm * 33mm * 8mm

Inside module: 284mm * 60mm * 29mm without knob and handle, 284mm * 60mm * 69mm with knob and handle
