Shelly Gas
Downloads
Manuals
Compliance
Shelly Gas multilingual EU declaration of conformity 2025-07-21.pdf
Shelly Gas LPG UK PSTI ACT Statement of compliance.pdf
Shelly Gas CNG UK PSTI ACT Statement of compliance.pdf
What is Shelly Gas?
A smart gas sensor
Many home appliances are dependent on natural gas, but not many homes have sensory detection for gas leaks, which can be dangerous. 2 types of Shelly GAS detector – Compressed Natural Gas (CNG) or Liquefied Petroleum Gas (LPG) are providing additional protection for your home and family. Its long life span, little sensitivity drift, and Wi-Fi technology allow you always to know if gas is threatening your home.
Features
No HUB required.
2 types of the gas detector – LPG or CNG
Sound and light alarm with an app notification.
Flame-resistant shell.
It can be integrated to work with all other Shelly devices.
Compatible with Android, iOS, Amazon Alexa, and home automation servers using MQTT, CoAP, and REST API.
Easily make your Arduino project live and usable in your automation project.
Specification
SPECIAL FUNCTIONS | |
Power supply AC |
110-230V ±10%, 50/60Hz |
Power supply DC |
No |
SPECIAL FUNCTIONS | |
Gas detector |
Compressed Natural Gas – CNG / Liquefied Petroleum Gas – LPG |
Device temperature protection |
Yes – Flame Resistant |
FEATURES | |
Alarm indicator |
LED Flash & Sound |
Alarm sensitivity |
6% LEL |
Sound level |
≥70dB |
Valve manipulator jack output |
11-13V, 500mA |
Operational temperature |
-10ºC to +50ºC |
Device power consumption |
< 3 W |
Intelligent On/Off |
Yes |
Local and remote control |
Yes |
CONNECTIVITY | |
Wireless/WiFi Protocol |
802.11 b/g/n |
Radiofrequency |
2400 – 2484 MHz |
Range |
up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
DIMENSIONS | |
Size |
89.5 mm x 89.5 mm x 38 mm (plug not included) |
